Linux System Monitoring: top, htop, vmstat, and iostat Explained

A slow Linux system tells you something is wrong, but not what. Is it CPU? Memory? Disk I/O? Network? Each problem has a different fix, and each fix requires the right diagnostic tool.

This guide covers the essential Linux monitoring commands — what they show, how to read them, and how to use them to find the actual bottleneck.

The First Question: What Kind of Problem Is This?

Before opening any tool, narrow it down:

• System feels sluggish overall → start with top or htop
• Commands are slow but CPU isn't pegged → likely memory pressure or disk I/O (vmstat, iostat)
• A specific process is misbehaving → top -p <PID> or watch ps
• Network feels slow → nethogs, iftop, ss
• Disk operations are slow → iostat, iotop

top — The Quick Overview

top gives you a real-time view of what's consuming CPU and memory.

top

Reading the header

top - 14:32:05 up 2 days, 3:12,  2 users,  load average: 0.45, 0.38, 0.31
Tasks: 183 total,   1 running, 182 sleeping,   0 stopped,   0 zombie
%Cpu(s):  3.2 us,  1.1 sy,  0.0 ni, 95.0 id,  0.5 wa,  0.0 hi,  0.2 si
MiB Mem :   7844.0 total,   2103.4 free,   3891.2 used,   1849.4 buff/cache
MiB Swap:   2048.0 total,   2048.0 free,      0.0 used.   3652.1 avail Mem

Load average (0.45, 0.38, 0.31) — 1, 5, and 15-minute averages. Compare to your CPU count:

• On a 4-core machine, load of 1.0 means 25% saturation — healthy
• Load of 4.0 means fully saturated — okay briefly, concerning if sustained
• Load above your core count means processes are waiting for CPU

CPU breakdown:

• us — user processes (your apps)
• sy — kernel (system calls, overhead)
• id — idle (how much headroom you have)
• wa — waiting on I/O (disk or network) — high wa means disk is the bottleneck
• hi/si — hardware/software interrupts

What to look for in top

• High %wa? Disk I/O problem — check with iostat
• High %sy? Too many system calls — often network or disk issues
• Low id and high us? CPU-bound — find the process consuming it
• Swap in use? Memory pressure — check with free and find memory hogs

Useful top shortcuts

Key	Action
M	Sort by memory
P	Sort by CPU (default)
k	Kill a process
u	Filter by user
1	Show per-CPU breakdown
q	Quit

htop — top with Better UX

htop shows the same information as top but with color bars and mouse support.

# Install if needed
sudo apt install htop       # Ubuntu/Debian
sudo dnf install htop       # Fedora/RHEL

htop

The CPU and memory bars are color-coded:

• Green — user processes (normal)
• Red — kernel/system (overhead)
• Blue — nice'd processes (lower priority)
• Yellow — I/O wait (disk waits)

htop is faster to read under pressure. Use top when htop isn't available; prefer htop when it is.

free — Memory at a Glance

free -h    # human-readable (MB, GB)
free -m    # megabytes
free -s 2  # refresh every 2 seconds

Output:

              total        used        free      shared  buff/cache   available
Mem:           7.7G        3.8G        2.1G        234M        1.8G        3.6G
Swap:          2.0G          0B        2.0G

Don't panic at "used" being high. Linux uses free memory for disk cache (buff/cache), which is released when applications need it. The number that matters is available — that's how much your programs can actually claim.

Column	What it means
total	Total installed RAM
used	RAM in active use
free	Completely unused RAM
buff/cache	Used for disk cache (reclaimed when needed)
available	Estimated memory available for new processes
Swap used	How much swap is in use — non-zero means memory pressure

Red flags:

• available near zero → system is close to OOM (out of memory)
• Swap in heavy use → RAM is exhausted, system will be slow

vmstat — CPU, Memory, and I/O at Once

vmstat shows a combined view of CPU, memory, swap, I/O, and system activity.

vmstat 2       # update every 2 seconds
vmstat 2 10    # 10 samples, 2 seconds apart

Output:

procs -----------memory---------- ---swap-- -----io---- -system-- ------cpu-----
 r  b   swpd   free   buff  cache   si   so    bi    bo   in   cs us sy id wa st
 1  0      0 2156744 112384 1892408    0    0     8    24  248  511  4  2 93  1  0

Column	Meaning
r	Processes waiting for CPU (run queue)
b	Processes in uninterruptible sleep (I/O wait)
swpd	Swap in use (KB)
free	Free memory (KB)
si / so	Swap in / swap out (KB/s) — non-zero is bad
bi / bo	Block reads / writes (KB/s)
us / sy / id / wa	CPU: user / system / idle / wait
cs	Context switches per second
in	Interrupts per second

What to watch:

• r consistently > CPU count → CPU saturation
• b > 0 → processes stuck waiting for I/O
• si/so > 0 → active swapping (memory exhaustion)
• High wa in CPU columns → disk is the bottleneck

iostat — Disk I/O Details

iostat shows disk read/write rates and how busy your storage devices are.

# Install if needed (part of sysstat package)
sudo apt install sysstat
sudo dnf install sysstat

iostat              # single snapshot
iostat -x 2        # extended stats, update every 2 seconds
iostat -x 2 5      # 5 samples

Output (extended mode):

Device     r/s   w/s  rMB/s  wMB/s  r_await  w_await  %util
sda       12.4  23.1    0.5    1.2     2.34     5.67   18.2
sdb        0.0   0.0    0.0    0.0     0.00     0.00    0.0

Column	Meaning
r/s / w/s	Read/write operations per second
rMB/s / wMB/s	Read/write throughput in MB/s
r_await / w_await	Average wait time for read/write (milliseconds)
%util	Percentage of time device was busy

What's normal:

• HDD: await under 10ms, %util under 70%
• SSD: await under 1ms, %util can sustain higher

Red flags:

• %util near 100% → disk is saturated
• await > 20ms on SSD → I/O queue backup
• Reads/writes much higher than expected → unexpected background activity

iotop — Which Process Is Using Disk

iostat shows disk usage totals; iotop shows which processes are responsible.

sudo apt install iotop
sudo iotop          # live view (needs root)
sudo iotop -a       # accumulated I/O since start
sudo iotop -o       # only show processes doing I/O

Like top but for disk I/O — shows bytes read/written per process per second. Essential when iostat shows disk saturation and you need to find the culprit.

df and du — Disk Space

df -h              # disk space by filesystem
df -h /var         # space on the filesystem containing /var
du -sh /var/log/   # total size of /var/log
du -sh /var/log/*  # size of each item in /var/log
du -sh * | sort -h # sorted by size, human-readable

Full disk kills services. When df shows 100% on /, most services stop writing logs and may crash. Common culprit: /var/log filling up.

# Find the largest directories under /var
du -h /var --max-depth=2 | sort -h | tail -20

Monitoring Network Usage

nethogs — per-process network usage

sudo apt install nethogs
sudo nethogs eth0    # shows bandwidth per process

iftop — per-connection network usage

sudo apt install iftop
sudo iftop -i eth0  # shows traffic by remote host

ss — active connections and listening ports

ss -tuln            # TCP/UDP listening ports, numeric
ss -tunap           # include process names
ss -s               # summary stats

Setting Up Continuous Monitoring with sar

sar (System Activity Reporter) from the sysstat package collects metrics continuously and lets you look back in time.

sudo apt install sysstat

# Enable data collection
sudo systemctl enable --now sysstat

# View historical CPU usage
sar -u             # today's CPU usage
sar -u 1 5         # live: 5 samples, 1 second apart
sar -u -f /var/log/sysstat/sa20  # data from the 20th

# View historical memory
sar -r

# View historical disk I/O
sar -d

After installing sysstat, it collects data every 10 minutes and keeps history. sar is invaluable for post-mortem analysis — "what was the system doing at 3am when the alert fired?"

A Monitoring Checklist for Slow Systems

1. top — is CPU or memory the immediate issue?
2. free -h — is memory available, or is swap active?
3. vmstat 2 — is there an I/O wait problem?
4. iostat -x 2 — which disk, and how saturated?
5. iotop — which process is doing the I/O?
6. df -h — is any filesystem full?
7. ss -tunap — any unusual connections?

Work through this in order and you'll identify most performance problems in under 5 minutes.
